Features

Precision oriented

Precision oriented

Fast specimen alignment — Patented 0 position indicator with clear graduation and pleasant motion feedback enables fast alignment of the specimens.

Steady moment — Motorized system offers steady and even-speed movement.

Sectioning you can feel — The coarse feed wheel provides precise tactile feedback with every rotation, giving you enhanced control and a deeper connection to the sectioning process for consistently superior results.

Ergonomics infused

Ergonomics infused

Minimized fatigue — Smooth and light hand wheel thanks to expertly designed force balance system.

Thumb design on the hand wheel for the thumb to rest on amid heavy workload.

Easy-to-clean waste tray — Large volume, removable waste tray with slope interior allows for effortless cleaning.

Rounded corner in every corner — Rounded corner in every corner protects laboratory technicians.

Bottom glider makes cleaning easier.

Adapt to users

Adapt to users

Position memory — Position memory function brings specimen head to the desired position in one touch.

3-in-1 coarse feed wheel — 3-in-1 coarse feed wheel with reversible wheel direction adapts to the microtomists' preference.

Rocking mode — Sensitive rocking mode allows trimming without a full rotation of handwheel, reducing fatigue.

Move specimen head in your way

Move specimen head in your way

Touch screen — Modify all parameters intuitively on the touch screen.

Control panel — Move specimen head easily with the built-in control panel.

External control panel — External control panel can be placed on either side of the microtome

Ultimate sectioning experience and reliability

Ultimate sectioning experience and reliability

Engineered mechanisms — Ultra-precise, sleek rail with cross roller bearings and force balance system bring ultimate sectioning experience and reliability.

Dovetail groove blade holder base guarantees stable, wobbling-free operation.

Fine step angle stepper motor provides precise sectioning.

Joint effort of engineering and art

Joint effort of engineering and art

Enlighten the laboratory — Two appearances available to enlighten the laboratory with a bit of color and art.

Specifications

Dimension (W × D × H)	490 × 570 × 306 mm
Weight	Approx. 38 kg
Power	100 - 240 VAC, 50/60 Hz
Maximum consumption	50 VA
Control panel	Built-in and external
Watse tray	Anti-static
Section thickness range	0.5 - 100 μm
Trimming thickness range	1 - 600 μm
Blade holder	High and low profile
Retraction	Adjustable
